Description
License PTM – allows to read & write FLASH & EEPROM of drive control modules PTM.
MAN truck.
MPC Microprocessor Controller MPC5554 (SPC6670) (Flash)
External flash M29W160EB (Flash)
Operation modes:
– OBD
– DC
– JTAG
Important Info:
– For the PTM Clone function, both PTM modules must have identical part numbers. Cloning is only possible when the PTM numbers match exactly.
– Cloning can be done only by reading & writing in JTAG mode.
Hardware requirements:
– VEI V6/V7/V8 device
– Direct Connect 2U tool with OBD2 power cable
– DC2-PTM cable or DC2-EDC17+PTM cable or DC2-EDC7+FFR+PTM cable
– DC2U-ISP-JTAG+BDM dongle
– DC2U-JTAG8 flex adapterTo use this license no need tokens. Can be used unlimited times.
– VEI V6/V7/V8 device
– Direct Connect 2U tool with OBD2 power cable
– DC2-PTM cable or DC2-EDC17+PTM cable or DC2-EDC7+FFR+PTM cable
– DC2U-ISP-JTAG+BDM dongle
– DC2U-JTAG8 flex adapterTo use this license no need tokens. Can be used unlimited times.
